105MM ER G3
Complete range of 105mm artillery ammunition
KNDS 105mm ER G3 ammunition range provides the armed forces with highly effective combat proven solutions designed to support a wide spectrum of indirect fire missions.
The ER G3 family offers improved range compared to its competitors thanks to its base bleed unit, all while maintaining maximum accuracy and terminal effect.
Fitted for use on NATO standard 105mm artillery systems, towed or self-propelled, such as the 105 LG, M101, M119 and L119 light gun both our 105mm shells share a common ballistic profile and ballistic characteristics.
ADVANTAGES:
- Compatible with 105LG, M101, M119, L119 light gun and equivalent NATO standard 105mm artillery guns
- Complete range of ammunition to fulfill a wide spectrum of indirect fire missions
- Both shells are fitted with a base bleed unit allowing for increased range
- The shell is fitted with two increments of propelling charges in order to fire at different ranges and muzzle velocities
- ITAR free
KEY CHARACTERISTICS
Round length
850mm
Cartridge mass
18kg
Projectile mass
13.1kg
Smoke screen duration
90s
Max operational range
17km
Muzzle velocity
685m/s
