30 mm cannon
Provides powerful firepower to neutralize light targets and armored vehicles at medium range.
Need more info?
ARX® 30
ARX®30
The ARX®30 provides a 360° protection with its capacity to neutralize infantry group and median protected land vehicles. It can be used for self-protection by infantry, convoy or static unit. The system is also tailored for urban area thanks to the versatility of munitions terminal effects
FACT ABOUT THE ARX®30
In a high intensity conflict, ARX®30 is a must-have considering its overmatch on smaller caliber and its incomparable compactness and maneuverability.
The ARX®30 can be used in very severe electromagnetic environment thanks to the 1A/1W NATO Standard Super Safe ammunition.
While upgraded, the ARX®30 can enhanced its 360° protection ability against mini and micro UAV.
ARX®30 RWS equipped of the 30M781 MPG gun replaces both 12.7 mm gun and 40mm Grenade Launcher RWS. The 30M781 MPG gun is the land version of the electrically driven 30M781 gun used on the Tigre helicopter.
This system can be adaptable on a large scale of plate-forms, from the 4x4 vehicles, to secondary armament for tanks (with no intrusion) and robots.
Modern fire control system
Ensures precise targeting and firing, even while moving, with advanced electronic equipment.
High mobility
Designed to integrate onto light, all-terrain vehicles, offering great flexibility in various environments.
Enhanced ballistic protection
Ensures crew safety by providing protection against modern battlefield threats.
Compact and lightweight
Its design allows easy integration onto different vehicle platforms, including those requiring rapid mobility.
Versatility
Suitable for a wide range of missions, including reconnaissance, fire support, and engagement of mobile and fixed targets in urban or challenging terrains.
Operational benefits
This system can be adaptable on a large scale of plate-forms, from the 4x4 vehicle, to secondary armament for tank (with no intrusion) and robots.
Following the global evolution to bigger caliber:
• Overmatch on 12.7 mm gun + GL 40mm
• Terminal effect > 12.7 mm gun + GL 40mm
• Practical range > 12.7 mm gun + GL40mm
• Efficiency ratio turret system vs. weight 30x113mm > 12.7mm +GL40mm
Multi mission
- Large choice of ammunition = versatility of terminal effect
- Adaptable on a large scale of vehicle
- Light and mobile
- Firing on the move
The ARX®30 can be proposed in 3 versions to adapt its missions:
- The ARX®30 is tailored to defeat soft or lightly protected targets thanks to its surface/surface ability, the ARX®30 RWS replace both GL 40 and the 12,7 mm RWS with a better practical range and terminal effect (due to its versatility of ammunition),
- ARX®30 NEROD: The ARX®30 surface/surface ability is coupled with the NEROD C-UAV weapon providing a capacity of treatment by jamming against non-military drones. This capacity is enhanced by the addition of video tracking,
- ARX®30 C-UAV: This version is the last upgrade of the ARX®30, the adding of a radar on the vehicle provide an ability of detection and identification. This upgrade coupled with the future ability of firing Airburst chronometric fuze delivers to the ARX®30 a complete C-UAV capacity against mini and micro UAV (NATO UAS classification).
Features
Weight
350-500kg (depending on options)
Sight
color CCD, uncooled IR and Eye safe LRF
Dynamic capabilities (operational range)
Azimuth nx360°
Elevation
-15°/+55°
Stabilization
2 axes
Detection system (Radar,...)
option
THE ARX®30 IN PICTURES
