Characteristics
Length: 350 cm Width: 190 cm Height: 120 cm Weight: 2900 kg
Need more info?
CENTURIO
CENTURIO
Heavy Wheeled Multi-Mission Tactical UGV
The CENTURIO robotic system (2 to 3 tons class) is a versatile platform designed for advanced military applications. It combines several key components:
FACTS ABOUT THE CENTURIO
- The CENTURIO robotic system (2 to 3 tons class) is a versatile platform designed for advanced military applications. It combines several key components:
- Rolling Platform: CENTURIO is based on the PHOBOS all-terrain vehicle, tested by SERA Engineering (SOGECLAIR group), providing robustness and mobility across the most challenging terrains.
- KNDS Robotics Kit: This kit includes advanced hardware (sensors and computers) and validated software, enabling secure teleoperation and incorporating autonomous capabilities for a variety of missions.
- Mission Module Kit: CENTURIO can be equipped with various payloads, such as a manipulator arm for tasks like bomb disposal or countermining, or weapon systems, including the ARX20 (CENTURIO-X20, with a 20mm cannon manufactured by KNDS). Thanks to its modularity, the CENTURIO system can also integrate a range of turret systems tailored to specific needs, ranging from a 7.62mm caliber up to 30mm.
FACTS ABOUT THE CENTURIO PIONEER
“PIONEER” version: based on CENTURIO robotized rugged platform by KNDS France, the Pioneer variant is dedicated to C-IED operati¬ons; using interchangeable tools, the robot can dig into the soil, confirm presence of suspicious objects and manipulate IED. These tasks contribute to protect soldiers from IED threats and to speed up the military maneuver.
The robot is remotely controlled using robust radio links (or fiber optic when operating in jammed environments). It proposes various assistances (including autonomous capabilities to reduce the operator‘s cognitive workload and improve efficiency.
Mobility
Engine power: Diesel 60 kW (JP8, Jet-fuel) Transmission: 4 WD, 4 WS Hydraulic Propulsion Velocity: 45 km/h Steering modes: ackerman, reverse ackerman, circle, parallele Slope: 60 % Spill: 40 %
Capabilities
360 °camera system Night vision (Infra-red and low light level) Front and rear lights PTZ camera vision
Robotic functions
Remote control Secured teleoperation up to 35 km/h Autonomous back on track capability Trajectory replay Range of radio link: > 5 km LOS
Transportation
Towing capability: up to 90 km/h
ARM
Degrees of freedom: 4 Multiple camera vision system Manipulate range: 3 m Lift capability: > 100 kg Tools: claw, bucket, air nozzle
FACTS ABOUT CENTURIO X20
« X20 » version: Based on CENTURIO robotized rugged platform by KNDS France, the X20 variant is equipped with a robotized 20 mm gun . The gun has been adapted to provide reliable and efficient remote operation; it is operated using a safe and secured radio link, which is also used to control the mobility of the platform. The remote operator always manages directly the gun (from target designation to shooting) but can be assisted by various autonomous capabilities to manage mobility. All armed versions of CENTURIO are equipped with a secure, jamming-resistant radio firing system, offering mesh networking capabilities to ensure reliable and safe operations.
Characteristics
Length: 350 cm Width: 190 cm Height: 120 cm Weight: 2800 kg
Mobility
Engine power: Diesel 60 kW (JP8, Jet-fuel) Transmission: 4 WD, 4 WS Hydraulic Propulsion Velocity: 45 km/h Steering modes: ackerman, reverse ackerman, circle, parallele Slope: 60 % (reduced with arm) Spill: 40 % (reduced with arm)
Capabilities
360 °camera system Night vision (Infra-red and low light level) Front and rear lights
Robotic functions
Remote control Secured teleoperation up to 35 km/h Autonomous back on track capability Trajectory replay Vehicle following
Radio links
Range of radio link: > 5 km LOS Secured firing radio link
Transportation
Towing capability: up to 90 km/h
Fire Power
ARX 20 RCWS Main armament: 20M621 cannon – 20x102 OTAN Secondary armament: MAG 58 machine gun - 7.62x51 mm Aiming and laying: Gyrostabilized Sight: dual field color camera; day and IR dual lens; night uncooled laser range finder
