ARX®20

ARX®20

The ARX®20 system is a 20 mm automatic cannon that combines high performance and operational flexibility.


no alt text

FACTS ABOUT THE ARX®20

It stands out for its ammunition versatility, capable of firing armor-piercing, high-explosive, and tracer rounds, making it adaptable to a wide range of targets, from armored vehicles to aircraft. Its high rate of fire (750 rounds per minute) and accuracy at long range (up to 2,000 meters) make it particularly effective against both moving and stationary targets at mid-range distances.

The ARX®20 features a modular design, allowing for easy integration onto platforms such as armored vehicles or naval ships, providing great adaptability. Its reliability and durability in extreme conditions (heat, cold, dust) make it a top choice for missions in harsh environments. Finally, the simplified maintenance of the ARX®20, thanks to its optimized design, ensures enhanced operational availability and efficient service time management.

The 20mm cannon superior firepower

  • Provides stand-offs against heavily gunned asymmetric threats (out of effective range of HMG)
  • Immediate stopping power
  • Destroys light armoured vehicles (STANAG 4569 Level 4)
  • Available version: 20M621 (20mmx102 NATO standard)
  • A longer effective range (50% higher than the 12,7 mm)

The 20mm ammunition efficiency

  • Firing explosive incendiary ammunition with high terminal effect
  • Superior Armour Piercing capacity
  • Easier and faster target neutralisation at longer firing range with reduced ammunition consumption (compared to Heavy Machine Gun)

Complete operability

  • Well suited for security missions and urban combat
  • Day/night observation over 360°
  • Observation and fire on the move (gyro-stabilised station)
  • Remotely-operated (crew protection)
  • Firing waste disposal for 20mm and 7.62mm ammunition

Easy integration on any carrier

  • Reduced weight and compactness. Low mechanical cons¬traints on the carrier. No intrusion into chassis
  • Designed to be integrated on different types of carriers, including light 4x4 vehicles and robots

Modular design

The ARX®20 gun benefits from a modular design, enabling easy integration on a variety of platforms, such as armored vehicles or naval defense systems.

Simplified maintenance

Thanks to its optimized design, the ARX®20 is easy to maintain, with accessible components enabling rapid and efficient servicing, thus increasing the operational availability of platforms.

Features

  • Total weight (Ready to fire)

    < 300kg

  • Average recoil force

    250daN

  • Slewing rate

    >60°/s

  • Traverse

    N x 360°

  • Elevation

    -15°/+60°

  • Aiming & laying

    Gyro-stabilised

  • Power supply

    28V DC

Sighting :

  • Dual field Colour Camera Day /IR Dual lens Night uncooled
  • Laser Rangefinder

Options :

  • 7.62mm Machine Gun (300 rounds)
  • Smoke dischargers GALIX
no alt text

THE ARX®20

no alt text
no alt text

Related products to the ARX®20

You will find many other products from KNDS France to accompany this one, which are associated with the product illustrated.

no alt text

ARX®30
