Characteristics
Length: 1.97 m (with side panels closed) Width: 1.30 m Height: 1.18 m Loading height: 0.9 m Adapted dimensions for dismounted operation support Weight: 800 kg Payload: 600 kg Temperature range: -20 °C to +49 °C
Need more info?
ULTRO
Wheeled 100% Electrical Multi-Mission Tactical UGV
ULTRO is an 800 kg, fully electric wheeled platform designed to support both mounted and dismounted tactical operations, including Direct Action and Reconnaissance missions. Like other robotized platforms from KNDS France Robotics, ULTRO can be equipped with a range of mission kits to handle reconnaissance, logistics, route clearing, and combat tasks. It is built to operate reliably and agilely across a variety of challenging terrains, such as paved roads, dirt tracks, grass, brush, rocky areas, sand, narrow trails, muddy swamps, and dense jungles, making it suitable for serious off-road conditions.
FACT ABOUT THE ULTRO
ULTRO offers a carrying capacity of up to 600 kg, providing versatile support for various mission needs. It has an operational autonomy of 4 to 9 hours in stand-by mode and can reach a maximum speed of 15 km/h. Engineered for extreme ground mobility, ULTRO is equipped with a high-torque, high-traction drivetrain, a low center of gravity, and the ability to climb steep inclines, ensuring reliable performance in challenging environments. Furthermore, ULTRO is adaptable with a wide range of mission kits, including a logistics tray, remote-controlled weapon systems (up to 12.7 mm), mine detection and ground penetration radar, DEMETER mine-luring technology, telescopic mast, UAV or micro-UGV trays, and more.
Mobility
100% electric and silent Reversible travelling direction Skid steering rotation (pivoting function) Easily adapts to all types of environment Sand ladders and off-road accessories Obstacle crossing: 40 cm to 60 cm (without/with ladders) Side-slope: 40% Incline: 35% Fording capability: 60 cm Max. speed: 18 km/h
Capabilities
360° camera system Night vision (Infra-Red and Low Light Level) Dazzling light 360° acoustic sensors Front and rear lights
Robotic functions
Remote control Pedestrian / Vehicle tracking Autonomous back on track capability Trajectory replay Mission modules Up-to 4 mission-module capability (dismounted personnel battery charger, telescopic arm, special sensors, etc.) Compatible with the NERVA mission modules (KNDS France)
Transportation
Towed by an infantry fighting vehicle Built-in towbars Recharged by the towing vehicle Sling loaded Military or civil air-transport Transport in KC20 type containers
Energy
Autonomy: 8 to 12 hrs Standby time: 24 hrs Standard 6T extractable batteries (Li-Ion) Batteries compliant with aviation regulation
